The cables manufactured by us are used as original wiring parts in auto harnesses and automobiles. We also produce Battery cable harnesses which are ready to be used in automobile manufacturing and are available in crimped or soldered type. Made from annealed pure bare conductors, these offer low resistance for conductors. As a special grade PVC compound is used as an insulator, it is also resistant to oil, water and acids.
Low Voltage Automobile Wire
Manufactured by us are thinner than normal AV wires and follow specification standards JASO D611-94. Available in different surface areas, their insulation thickness ranges with wires withstanding current. Light in weight and utilizing less space, these are used mostly in motorcycles and other vehicles.
Features:
- Thinner than AV wires
- Used for light weight and smaller space
Type ET (250 V ACrms working) RJ 0501
| Size | Conductor Strands | Conductor Diameter | Conductor Resistance 20ºC | Insulation Thickness | Overall Diameter (Standard) | Current Limit |
| mm² | No./mm | mm | Ω/km | mm | mm | Amps |
| 0.3f | 15/0.18 | 0.8 | 48.9 | 0.5 | 1.8 | 9 |
| 0.3 | 7/0.26 | 0.8 | 50.2 | 0.5 | 1.8 | 9 |
| 0.5 | 7/0.32 | 1 | 32.7 | 0.5 | 2 | 12 |
| 0.85 | 11/0.32 | 1.2 | 20.8 | 0.5 | 2.2 | 16 |
| 1.25 | 16/0.32 | 1.5 | 14.3 | 0.5 | 2.5 | 20 |
| 2 | 26/0.32 | 1.9 | 8.81 | 0.5 | 2.9 | 27 |
| 3 | 41/0.32 | 2.4 | 5.59 | 0.6 | 3.6 | 37 |
| 5 | 65/0.32 | 3 | 3.52 | 0.7 | 4.4 | 50 |
