LFH Cables

Low Attenuation

The low attenuation of LHF coaxial cable series provides efficient transmission line for your RF system.

Low VSWR

The low VSWR of LHF coaxial cable series should guarantee your RF system without noise.

Complete Protection

The outer conductor of LHF coaxial cable series makes important contribution to minimize system interferences.

Easy connecting

Full line of high-quality connector and cable preparation tools to minimize installation time and cost

S.No.	Item: Cable LFH 600V Single Core	Unit	24AWG	22AWG	20AWG	18AWG	16AWG	14AWG	12AWG
1	Make		RJ INDUSTRIAL CORPORATION
2	Type		SINGLE CORE UNSHIELDED
3	No. of Cores		1 core
4	Reference Standards	---	JSS51022
5	Temp.range	Degc	(-)50 to +120
6	Conductor		(-)50 to +120
	Strand diameter	mm	0.13	0.16	0.2	0.25	0.29	0.25	0.32
	No. of Strands	nos	19	19	19	19	19	37	37
	Cond.dia max.	mm	0.62	0.80	1.04	1.29	1.53	1.82	2.35
7	Insulation		Extruded
	Material	---	LFH
	Core dia (approx.)	mm	1.05 TO 1.35		1.3 TO 1.55	1.55 TO 1.80	1.8 TO 2.1	2.15 TO 2.35	2.75 TO 3.1
	Colour		As desired
8	Electrical Test
	High Voltage at room temp.	KVAC	2.5
	Spark test	KVAC	5.0
	Conductor resistance, Ω/Km (At 200C)		95.6	60.0	33.2	21.1	14.5	10.9	6.63
	"Insulation resistance, M ohm-Km min At 20±20C"		0.2
9	Tests on isulation
	Critical Oxygen Index Test	%	29 (min)
	Smoke Index Test	%	12 (Max)
	Toxicity Index Test	-	0.2/100gm (max)
	Temperature Index Test ,0C	0C	250 (min)
	Hydrochloric Acid Gas Contents (As per IEC 754-II)	-	NIL (pH-4.3 min. &Conductibity-10µS/mm (max.)
10	Packing	Meter	100m and above with max 20% of PO qty in 20 to 99m in plastic spools.
