PTFE electrical sleeveings are available as per Indian Defense Standard JSS 54802(LCSO approved), these sleeves are made from PTFE tape by wrapping & sintering process
Application:
- Radar, satellites and other defense electronic equipments
- Due to high temperature proximity widely used for heater qinterconnections
- RF signal transmission antennas
- Temperature sensors, automobiles
- Communications, control instruments and professional electronics.
Make Up:
PTFE tape of appropriate colour wrapped and sintered.
Colour Codes:
Black, Brown, Red, Orange, Yellow, Green, Blue, Violet, Grey, White, Pink and bicolours.
Technical Data:
- Indian Defense Standard JSS 54802
- 20 x Sleeve dia
- Working Temp.: -65 C to +260 C
Product Features:
- Non-flammable
- High dielectric strength
- Extremely stable at high temperature and can be used o ocontinuously at -65 C to +260 C
- Operating temperature: -50℃～105℃
| Part Number | Inner diameter in mm | Wall thickness in mm | Weight gms/mtr approx. | 0verall diameter max. mm |
| RJ 1201 | ||||
| 1201 00001 | 0.50 | 0.25 | 1.31 | 1.00 |
| 1201 00002 | 0.75 | 0.25 | 1.74 | 1.25 |
| 1201 00003 | 1.00 | 0.30 | 2.70 | 1.60 |
| 1201 00004 | 1.50 | 0.40 | 5.30 | 2.30 |
| 1201 00005 | 2.00 | 0.40 | 6.70 | 2.80 |
| 1201 00006 | 2.50 | 0.40 | 8.10 | 3.30 |
| 1201 00007 | 3.00 | 0.40 | 9.50 | 3.80 |
| 1201 00008 | 3.50 | 0.50 | 14.00 | 4.50 |
| 1201 00009 | 4.00 | 0.50 | 15.70 | 5.00 |
| 1201 00010 | 5.00 | 0.50 | 19.20 | 6.00 |
| 1201 00011 | 6.00 | 0.50 | 24.30 | 7.00 |
| 1201 00012 | 7.00 | 0.50 | 28.00 | 8.00 |
| 1201 00013 | 8.00 | 0.50 | 32.40 | 9.00 |
| 1201 00014 | 9.00 | 0.50 | 36.80 | 10.00 |
