F-Series
PTFE F-Series is called Fine Powder and can be used in paste extrusion molding by adding an oil for luburicant. It is suitable for thin-walled tubes, thin rods and wire coating.
D-Series
PTFE D-Series is nano particle aqueous dispersion stabilized with a nonionic surfactant. It is manufactured through condensing raw dispersion from emulsified polymerization of PTFE. It is used as various film for construction or conveyor belts in food factories by impregnation and heat processing (sintering) on carbon fiber cloth or glass cloth.
F-Series
| Grades | Average Particle Size(μm) | Draw Down Ratio * | Features |
| F-104 | 400 - 650 | Low | Suitable for tubes, unsintered tapes and thick coaxial cables. |
| F-201 | 450 - 650 | Med. - High | Standard grade for tubes and wire coating |
| F-205 | 400 - 650 | Medium | Superior in heat resistance and good transparency.
Suitable for tubes and wire coating with heat resistance. |
| F-208 | 450 - 650 | Med. - High | Suitable for thin tubes and wire coating with heat resistance. |
| F-302 | 450 - 600 | Low - Med. | Superior in self-fusing property. Suitable for tubes. |
*Rough Indication for R.R (Reduction Ratio).
Low Reduction Ratio: Below 500
Medium Reduction Ratio: 200 - 1200
High Reduction Ratio: over 1000
D-Series
| Grades | Average Particle Size (μm) |
Specific Gravity (25℃) |
Features |
| D-210C | Approximately 0.2 | Approximately 1.5 | Suitable for glass cloth impregnation and metal impregnation. |
