Areas with high ambient temperatures and additionally high
Application:
- Boiler Rooms, Turbine Controls
- Steel Plants, Diesel Locomotives
- High Voltage Furnace Equipments
Product Features:
- Flame & radiation resistance
- Ozone & sunlight resistance
- Resistant against a multitude of oils, alcohols, vegetable and animal fats and chemical media
Colour Codes:
- Colour: Coloured (Black, Red, Blue, Brown, Yellow, Grey,White, Green, Orange)
Benefits:
- Longer durability in harsh applications than conventional qsilicone cables
- Good flexibility ease the installation where space is limited
- Good flexibility ease the installation where space is limited
Make Up:
- Fine strands of tinned copper wires
- Silicone rubber insulated
Technical Data:
- Indian Standard IS 9968/ IS 6380
Based on
Specific insulation resistance
- 20 GOhm x cm
Conductor stranding
- Fine wire in accordance to VDE 0295 Class 5 / IECQ60228 Class 5
Minimum bending radius
- Oscillating flexing: 15 x cable diameter
- Fixed installation: 4 x cable diameter
Rated voltage
- Up to 1.5 mm²: U0/U: 300/500 V
Test voltage
- 2000 V (Spark Test)
Range of temperature
- -55°C up to +180°C if adequate ventilation provided
