This cable is used in extinguishing systems to operate sprinklers & control panels. Application usage can be found in exit lights in high-rise buildings, hotels, hospitals, sub-ways, public facilities.
Product Features:
- Fire resistant, Low smoke
- Good chemical resistance
Colour Codes:
- Generally cable is made in orange colour but colour can be customized as per requirement Colour(Black, Red, Blue,Brown, Yellow, Grey, White, Green)
Technical Data:
Specific insulation resistance
- 20 G Ohm x cm
Make Up:
Specific insulation resistance
- Fine strands of electrolytic grade copper wires
- Mica Tape Fire Barrier
- FR/FRLS Compound insulation
Conductor stranding
- Fine wire in accordance to VDE 0295 Class 5 / IEC 60228 Class 5
Minimum bending radius
- Oscillating flexing: 15 x cable diameter
- Fixed installation: 4 x cable diameter
Rated voltage
- 450/750 V
Test voltage
- 2.5 KV/5 min
FRLS/Flame Properties
- Oxygen Index as per ASTM D 2863
- Temperature Index as per ASTM D 2863
- Smoke Density Rating as per ASTM D 2843
- HCL Acid Gas Generation as per IEC 754/Pt-1
- Flammability Test as per IEEE-383
- Swedish Chimney Test as per SEN-SS4241475
- Thermal Stability as per IS:10810 Pt. 60
- Fire Survival Test as per IEC-331
